Orbea Terra H30

Orbea Terra H30
  • Color: Light Green
  • Color: Black
  • Color: Military Green
$2,100.00 - $2,399.00
$2,399.00 - $2,400.00
Color: Light Green
Size: Select size
Please select options Unavailable


Of course you're not lost, you just aren't quite sure if this road is the quickest route to the next ridge. The weather is great, you've got all day and you're riding Terra, so keep the wheels rolling. If route-finding, taking the long way home, and straying from the beaten path are your ideas of fun, there is no better tool than Terra for unlocking your desire to explore.

All Road Geometry
- Control in a variety of circumstances. Terra is designed to be at home on dirt, gravel, or just about anything else you might encounter.
- Terra ergonomics work for cyclocross, all-day rides, and the occasional long training day on the road.
- Handling is precise and intuitive. Angles and dimensions are considered carefully across a range of sizes to maximize rider comfort.

- Terra can fill several roles—Gravel, Road, CX, Winter Training, or Commuting. Tire Clearance and the ability to mount accessories like mudguards, combined with a functional All-Road Geometry, means that Terra can change with the seasons.


Frame Orbea Terra Hydro disc, hydroformed triple butted aluminium, tapered 1-1/8" - 1.5", BB 68mm – BSC English, Thru Axle 12mm x 142mm rear, thread M12x P1.5, DT internal cable routing, 27.2mm seat tube, MMS system
Fork Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8" - 1.5", carbon dropouts Thru axle 12mm x 100m, thread M12xP1.5, MMS system
Headset FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings
Axles Front: Orbea Thru Axle 12x100mm M12xP1.5 Hollow
Rear: Orbea Thru Axle 12x142mm M12xP1.5 Hollow
Rims/Wheels Ready GR
Hubs Shimano RS470 28H
Tires Vittoria Terreno Dry Gravel G2.0 TNT 700x38c
Crankset Shimano GRX RX600 30x46t
Chain Shimano HG 601
Front Derailleur Shimano GRX RX810
Rear Derailleur Shimano RD-RX810
Cassette/Rear Cogs Shimano 105 R7000 11-34t 11-Speed
Shifters Shimano ST-RX600
Handlebars OC1 All Road, reach 80mm, drop 125mm, flare 12º
Stem OC1 31.8mm interface -6º
Brakes Shimano RX400 Hydraulic disc
Pedals Sold separately
Saddle Selle Royal Seta RS
Seat Post OC2 27.2 Offset 20

* Subject to change without notice.


Part Numbers

Option UPC MPN Store SKU
Light Green / XX-Small 08434446766732 L11046BM
Light Green / X-Small 08434446766763 L11049BM
Light Green / Medium 08434446766824 L11055BM
Light Green / Large 08434446766855 L11058BM
Light Green / X-Large 08434446766886 L11061BM
Black / XX-Small 08434446766718 L11046BK
Black / X-Small 08434446766749 L11049BK
Black / Small 08434446766770 L11052BK
Black / Large 08434446766831 L11058BK 210000037712
Black / X-Large 08434446766862 L11061BK
Military Green / XX-Small 08434446766725 L11046BL
Military Green / X-Small 08434446766756 L11049BL
Military Green / Small 08434446766787 L11052BL
Military Green / Medium 08434446766817 L11055BL
Military Green / Large 08434446766848 L11058BL
Military Green / X-Large 08434446766879 L11061BL
